MIL-DTL-28950C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
32 Seam reinforcement stay to armhole and
shoulder. (cont'd)
a. Seam the 3/4 inch wide polyester
301
SSaa-1
10-14
A
A
twill stays to the underside of the
fronts along the shoulder edge and
upper front edge of armhole,
respectively, 1/8 inch from the outer
edges. The top end of the armhole
stay and the lower edge of the
shoulder stay shall form a right angle
at the armhole without the stays
overlapping each other
33 Bind lower fronts.
Finished appearance. The binding
shall be uniformly stitched and shall
not be tight or full causing puckers,
gathers, or pleats. The basic
material and edges of binding shall be
securely caught in the stitching. The
outside raw edge only of the binding
shall be turned under and caught in
the stitching.
a. Bind the raw back edge of the
301
BSb-1
10-14
A
A
lower fronts with 3/4 inch wide bias
binding, turning under the outside raw
edge of binding only and catching the
turned under portion in the stitching
1/16 inch from the inner folded edge.
The binding shall extend from the
waist seam to the bottom edge of
fronts.
34 Assemble fronts.
Finished appearance. All chest and
waist darts shall be properly tapered
and shall finish without gathers,
puckers, or pleats. The upper and
lower fronts and side body panels
shall be joined without gathers,
puckers, or pleats.
a. The fronts shall consist of an
upper front, a side body front, and a
lower front (skirt).
36
