MIL-DTL-28950C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
25 Assemble inside pocket on left facing
(see Figure 9).
a. The inside pocket shall be made of
two pieces of polyester twill with a
facing of rayon lining at the vertical
piped pocket opening.
b. Position the rayon facing on the
301
LSd-1
10-14
A
A
two pieces of pocket material with the
(each
top and front edges even. Turn under
edge)
the inside and bottom edges,
respectively, of the facing and seam
to the pocket 1/16 to 1/8 inch from
the folded edges, catching the lower
edge of the identification label in
the stitching at the inside edge of
facing.
c. Seam the remaining three edges of
301
SSa-1
10-14
A
A
label to pocket material 1/16 inch
from each edge.
d. Mark the left facing for the
position of the pocket opening as
indicated by the marks on the
patterns.
e. Position the two front edges of
pocket in lining with the mark for the
pocket opening, with the pocket facing
next to the front facing.
f. Seam the pocket to the facing
301
SSv-1
10-14
A
A
through all plies, with one row of
stitches 3/16 to 1/4 inch on each side
of the mark for the pocket opening
g. Cut the facing only for the pocket
opening midway between the two rows of
stitches. Tongue notch each end of
the opening.
h. Turn the pocket through the
301
BSp-2
10-14
A
A
opening to the inside. Form the
piping at the front and back edge of
the opening. Topstitch the front and
back edges of the pocket opening
adjacent to the seamed outer edges of
the piping.
i. Tack the ends of the piping at the
301
SSa-1
10-14
A
A
underside, catching the tongue notches
at each end of the pocket opening in
the tacking.
31
