MIL-DTL-28950C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
12 Make shoulder straps.
(cont'd)
g. Press the straps smooth and flat
with a heated pressing iron or
pressing machine. The strap shall be
uniform in shape and size in
accordance with the pattern. The
seams shall finish at the edges of the
straps.
h. On the finished coat, the straps
shall measure 2-3/8 + 1/8 inches wide
at the armhole seam and shall taper to
1-3/4 + 1/8 inches at the eyelet end
of the buttonhole.
13 Make collar (see Figure 8).
Finished appearance. The completed
collar shall finish smooth and flat
without distortion. Edges shall be
uniformly even. The edge stitching
shall be uniform.
a. The collar shall be made of one
ply each of basic material, polyester
twill, cotton buckram and lining.
b. Seam polyester twill and cotton
301
SSa-1
10-14
A
A
buckram together 1/8 to 1/4 inch from
all edges and trim polyester twill
even with edges of buckram.
c. Lap the upper edge of polyester
301
LSa-1
10-14
A
A
twill side of interlining
approximately 1/2 inch on the inside
of the upper edge of the collar outer
ply and seam together 1/4 inch from
the raw edge of interlining. The
outer ply shall extend not less than 1
inch at each end of collar
interlining.
d. Smooth fold the outer ply over the
Hand
2-3
C
upper and lower edges of the
(silk)
interlining. Tack the portion of
outer ply folded to inside at the
lower edge to polyester twill
interlining. Stitching shall not be
through outer ply of collar.
25
