MIL-DTL-28950C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
10 Make upper pockets.
(cont'd)
c. Tack the abutted edges of the
103
SSm-1
6-8
A
-
pleat together on the inside of the
pocket with blind stitching.
d. Bind the upper edge of the pockets
301
BSc-1
10-14
A
A
with 1-1/8 inch wide bias binding,
with the pleat closed and both edges
of the binding turned under and caught
in the stitching 1/16 inch from the
inner folded edges of the binding.
e. Turn under and crease the side and
bottom edges of the pockets in a
heated edge creasing machine.
-or-
f. Fold the pocket in half lengthwise
301
OSf-1
10-14
A
A
and stitch 1-1/2 inches from folded
edge.
g. Form the pleat and seam across the
301
SSa-1
10-14
A
A
top and bottom edges, respectively,
1/16 to 1/8 inch from edge.
h. Baste the center of the pleat by
301
Hopper
machine.
i. Press pleat flat and smooth with a
heated pressing iron or pressing
machine.
j. Bind the upper edge of pockets
301
BSc-1
10-14
A
A
with 1-1/8 inch wide binding, with the
pleat closed and both edges of the
binding turned under and caught in the
stitching 1/16 inch from the inner
folded edges of the binding.
k. Mark the patch pocket in
accordance with the pocket shaper and
trim the lower corners of the pocket
for better turning.
l. Turn under the side and bottom
101
edges of pocket at the marks and baste
or
along the edges.
Hand
22
