MIL-DTL-28950C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
4 Make belt loops and keeper.
Finished appearance. The belt loops
and keeper shall finish 1/2 inch wide
and shall finish smooth and flat
without pleats, gathers, puckers, or
other distortions. The stitching
shall be uniformly 1/8 inch from the
finished edges.
a. The belt loops and keeper shall be
made from a 1 inch wide strip of basic
material.
b. Fold the sides of the strip
406
EFh-1
12-16
1
A
lengthwise towards the center,
(silk)
(silk)
abutting the raw edges, and join the
edges together with a covering stitch.
c. Cut the loop for the left and
right sides of the coat 5-1/2 inches
and 3-1/2 inches long, respectively.
d. Cut the keeper 4-1/2 inches long,
Bartack
28 per
A
A
fold in half, end to end, and join the
bartack
ends with a bartack across the width
of the keeper. The finished keeper
shall measure 2-1/8 + 1/8 inches from
bartack to folded end.
5 Make belt fastener (standard belt
only) (see Figure 6).
Finished appearance. The belt
fastener shall finish 1/2 to 5/8 inch
wide and shall finish smooth and flat
without pleats, gathers, puckers or
other distortions. The buttonhole
shall be clean cut and well made to
fit a 22-line sewing hole button. The
purling of the buttonhole shall be on
the outside of the fastener.
a. The belt fastener shall be made
from a 1-5/8 inch wide strip of rayon
lining material.
b. Fold the strip in half lengthwise,
301
EFp-2
10-14
A
A
turn in the raw edges, and stitch 1/8
inch from each side, catching turned
edges in the stitching to form a 1/2
to 5/8 inch wide band. Cut the
fastener 6-1/2 inches long.
14
