MIL-DTL-28950C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
35 Set pockets and pocket flaps.
Finished appearance. The pockets and
pocket flaps shall be set without
twists, gathers, puckers, pleats, or
raw edges. The stitching for the
raised edge of the flaps shall conform
to stitching for setting the pockets.
The side edges of the pockets shall
not be exposed beyond the sides of the
flaps. The pockets and pocket flaps
on the left and right side,
respectively, shall be in horizontal
alignment with each other. The front
edges of the pockets, pocket flaps,
and pleats on the upper pockets shall
be in parallel alignment with front
edge of coat when buttoned. The point
of the upper pocket shall be at the
center of the pleat on the upper
pockets. The center of the pleat on
the upper pockets shall be aligned as
accurately as possible with the waist
darts in the fronts. On the finished
coat, the top edge of the bottom
pocket flap shall be parallel with the
waist seam line, and the front edge of
the flap shall be in line with the
front edge of the upper pocket. The
lower front corners of the bottom
pocket shall be 3/8 inch further back
towards side seam. Pockets and pocket
flaps shall conform to the
measurements in Table III.
a. Mark the fronts in accordance with
the marks on the pattern for position
of upper and lower pockets and pocket
flaps.
b. Position the pocket flaps on the
outside of the fronts in accordance
with the marks for the upper and lower
pocket flaps, respectively. Position
the polyester twill stay piece for the
flaps and top corners of the pockets
on the underside of the fronts.
c. Seam the pocket flaps to the
301
LSq-2
12-16
A
A
fronts through the polyester twill
(a)
(silk)
(silk)
stay uniformly 1/8 inch from the
serged edge of the flap.
38
