MIL-DTL-21083E(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
N
OPERATION
TYPE
TYPE
STCH/IN
NDL
BOB/LPR
O
4
Make buttonhole tab.
2
Finished appearance. The sword
slit buttonhole tab shall finish
smooth and flat without
distortion. The stitching shall
be uniform and the buttonhole
shall be properly positioned. The
tab shall finish 2-3/8 + 1/8
inches long and 2 + 1/8 inches
wide.
a. Buttonhole tab for sword slit
shall be made of one ply of basic
material and one ply of rayon
lining material.
b. Seam together the lining piece
301
SSe-2
12-16
A
A
and basic material at side and
(shows
(silk)
(silk)
bottom edges of tab 3/16 inch and
finishe
turn topstitch 1/8 inch from
d seam)
seamed edge.
c. Seam the pieces together 1/8
301
SSa-1
12-16
A
A
inch from row edges at top end of
(silk)
(silk)
tab.
d. Make a vertical eyelet-end
Button
60 per
B
F
taper-bar type buttonhole, cut 5/8
-hole
(silk)
(silk)
inch long, in center of tab with
button-
the inside edge of the buttonhole
hole
eyelet placed 5/8 inch above
(incl.
bottom edge of tab. The
tack)
buttonhole shall be well worked
over gimp to fit a 22-line sewing
hole button. The purling of the
buttonhole shall be on the lining
side of the tab.
4
Make sword slit and attach
3
buttonhole tab (see Figures 6 and
7).
Finished appearance. The sword
slit shall finish without bulges
or excessive bulkiness. All parts
shall be securely fastened and
properly positioned. The flap
shall be securely attached and
properly positioned to cover slit
properly.
47
