MIL-DTL-21083E(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
N
OPERATION
TYPE
TYPE
STCH/IN
NDL
BOB/LPR
O
d. Close the opposite end of the
502
EFd-1
10-14
A
A
belt with overedge stitching.
or
503
EFd-1
10-14
A
A
e. Finished width of the belt
shall be 1-3/4 + 1/16, -1/8
inches. The finished length of
the belt for each size coat shall
be as shown in Table II.
Make buttonhole in belt (see
8
Figure 5).
Finished appearance. The
buttonhole shall be clean cut,
well made and correctly
positioned. The buttonhole shall
be the straight type and shall be
made to fit a 22-line sewing hole
button. The purling of the
buttonhole shall be on the outside
of the belt and the ends of the
buttonhole shall be securely
tacked.
a. Make a horizontal, straight
Button
50 per
A
A
type buttonhole, cut 5/8 inch
-hole
long, midway between upper and
button-
lower finished edges of the belt,
hole
(min)
with the center of the buttonhole
(incl.
1 + 1/8 inch from the overedge
stitched end and with the ends of
tack)
buttonhole securely tacked.
9
Sew on belt buttons (see Figure
5).
Finished appearance. The button
shall be positioned and securely
sewn to the belt with the ends of
the stitching securely tacked.
a. Mark the underside of the belt
for the location of two 22-line
sewing hole buttons. The center
of the button for the buckle end
shall be 3-5/8 + 1/8 inches from
the overedge stitched end of the
belt. The button for the belt
fastener shall be positioned in
accordance with mark on pattern
for each size belt.
19
