MIL-DTL-28919B(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
7
Make hip pocket flaps.
(cont'd)
c. Turn the flaps, working out the
301
SSe-2
10-14
0
0
seamed edges, corners and points
(b)
completely. Edge stitch the seamed
edges of flaps uniformly 1/16 to
3/32 inch from seamed edges,
working the lining or under ply
back from the finished edge of the
flaps. The lining underply shall
not be exposed on the outside.
d. Make a vertical, eyelet end,
Button-
52-54
0
0
taper bar type buttonhole cut 5/8
hole
per
inch long hole through the center
button-
hole
of the flap with the edge of the
incl.
eyelet 1/2 to 5/8 inch above the
bartack
center point. Buttonholes shall be
well worked over gimp to fit a
22-line button with the ends of the
buttonholes securely tacked. The
purling of the buttonhole shall be
on the outside of the flaps.
e. The finished hip pocket flap
shall measure 5-1/4 + 1/8 inches
across top.
8
Make left fly.
Finished appearance. The left fly
shall finish smooth and flat
without twists, puckering or
distortion. The everedge stitching
shall be securely caught in the
fabric.
a. Position slide fastener on left
301
LSbj-2
10-14
50/3
50/3
fly and left fly interlining with
or
bottom end of chain 1/4 to 1/2 inch
401
LSbj-2
10-14
50/3
50/3
above the fly notch. The front
edge of chain shall be 1/2 to 5/8
inch from front edge of finished
fly at top, tapering from 1/4 to
3/8 inch at the bottom. Stitch
slide fastener tape to the fly
through the interlining with a
double row of stitches 3/16 to 1/4
inch gage.
b. Overedge stitch the back edge
503
SSa-1
6-10
70/2
70/2
of left fly and left fly
or
interlining together.
504
SSa-1
6-10
70/2
70/2
14
