MIL-DTL-43415D
TABLE III. Manufacturing requirements - continued
Seam &
Stitches
Thread
Stitch
Stitching
per
Bobbin/
No.
Operation
Type
Type
Inch
Needle Looper
16. Position socket holes and attach buttons
and chin straps. (cont'd)
a. Position socket holes on the band so
that the center of each socket is
5-5/8 + 1/16 inches each side of center
front of cap and 7/16 + 1/16, -0 inch from
bottom edge of band.
b. Neatly punch the bottom socket holes
through band, inner body band.
c. Insert bottom socket posts and stitch
Hand
----
4-6
A
----
through inner body band. The socket post
shall be positioned so that the eagles on the
buttons will be in an upright position when
buttons are secured.
-- or --
The button socket posts shall be
inserted and a securing staple clinched
tightly over the center of the screw tube
flange on the inside of the band.
d. Attach chinstrap to post and attach
buttons into the posts with the eagle in an
upright position. The outer band shall not
show between binding and chinstrap.
