MIL-DTL-43415D
TABLE III. Manufacturing requirements - continued
Seam &
Stitches
Thread
Stitch
Stitching
per
Bobbin/
No.
Operation
Type
Type
Inch
Needle Looper
10. Join band to sides and sides to crown.
(cont'd)
c. Turn crown seam and side seam
301
LSq-2(b)
8-10
A
A
allowance towards crown and raise stitch
crown, 1/16 to 3/32 inch from turned edge.
11.
Set eyelets.
a. Position one eyelet in center of front-
piece (+ 1/8 inch off center tolerance) and 1
+ 1/8 0 inches above top edge of band,
measured to center of eyelet. The eyelet
shall be inserted through the front and front
stay and shall be backed with a washer
b. Insert two eyelets in each side of cap,
through front and support and through side
quarters, positioned 1 + 1/8, -0 inches from
top edge of band and 1 + 1/8 inches from
each side of the front and side joining
seams. Measurements shall be to center of
eyelets. The eyelets may be backed with a
washer.
12.
Set inner body band.
Finished appearance. The inner body
band and the binding shall be so attached in
the cap that there will be no twisting,
puckering or distorting of the outer band.
The front stay shall be between the inner
body band and the binding on the finished
cap.
