MIL-DTL-43415D
TABLE III. Manufacturing requirements continued
Seam &
Stitches
Thread
Stitch
Stitching
per
Bobbin/
No.
Operation
Type
Type
Inch
Needle
Looper
3. Shade and size marking.
Mark, ticket or bundle all component
parts made of the basic material to
insure a uniform shade and proper
assembly throughout the cap.
4.
Make inner body band.
a. Cut inner body band to proper
length.
b. Overlap ends of band 3/4 to
1-1/4 inches and secure with two
staples through the overlap portion.
5.
Join crown protector to crown.
Finished appearance. The crown
protector shall not be exposed on the
outside of the finished cap. The crown
protector shall not be twisted in the
stitching.
a. Position the identification card holder
protector with the 3 + 1/8 inch sides
toward the front and back of the cap
and the 1-5/8 + 1/8 inch sides toward
the sides of the cap. The card holder
shall be centered (1/2 inch off center
tolerance) and 2-1/2 inches from the
front edge of the crown protector.
88p14" style="font-size:12px">14
