MIL-DTL-43415D
TABLE III. Manufacturing requirements - continued
Seam &
Stitches
Thread
Stitch
Stitching
per
Bobbin/
No
Operation
Type
Type
Inch
Needle Looper
.
14. Make and attach sweatband .(cont'd)
Neither the edge of the welt nor the
edge of the sweatband shall be exposed
beyond the lower edge of cap.
a. Fold welt in half lengthwise.
304
----
12-14
E
E
Position edge of sweatband 1/16 to 3/32
inch from turned edge of welt and join
with a row of zigzag stitching.
b. Butt ends of sweatband and welt and
join with a row of zigzag stitching,
reinforced on the underside with a 5/8 +
1/16 inch strip of cotton fabric.
c. Position finished sweatband to cap and
301
----
6-8
16-4
16-4
stitch to cap with stitching through welt
and adjacent to edge of artificial leather
sweatband.
15. Block caps.
Finished appearance. The caps shall be
uniformly blocked and shall not be
distorted in the blocking.
16. Position socket holes and attach buttons
and chin straps.
Finished appearance. The chin strap
shall fit smooth and snug to band of cap
without twists or distortion.
104p20" style="font-size:12px">20
