MIL-DTL-43415D
TABLE II. List of pattern parts
Material
Nomenclature of pattern parts
Cut parts
Cloth, coated, artificial leather
Crown 1/
1
Front
1
Side (quarters)
2
Vinyl plastic film (0.0040 inch thick)
Crown protector 1/
1
Nylon knitted cloth (Raschel)
Front support
1
Laminated visor material
Visor (to show size and shape)
1
Front stay
Cotton sateen cloth
Cover
1
Polyethylene or polypropylene (0.020
Reinforcement
inch thick)
1
1/ Same pattern part.
3.7 Construction.
3.7.1 Stitches, seams, and stitching. Stitch, seam, and stitching types as specified in Table III shall
conform to ASTM-D-6193. Whenever two or more methods of seam/stitch types are given for the
same part of the operation, any one of them may be used. Where stitch types 101 or 401 is used, the
chain or underside of the stitch shall be on the inside of the cap.
3.7.1.1 Seam type. Seam types shall be as specified in Table III, with seam allowances maintained
and seams sewn so that no raw edges, runoffs, twist, pleats, puckers, or open seams result.
3.7.1.2 Thread breaks and ends of seams. Ends of all seams and stitchings, produced with 301
stitch type, when not caught in other seams or stitching shall be backtacked not less than 1/4 inch,
except that ends of a continuous line of stitching shall overlap and shall not be backtacked, regardless of
stitch type used. Thread breaks (all stitch types) shall be secured by stitching back of the break not less
than 1/2 inch. Skipped stitches or thread breaks (401 or 101 stitch type) may be repaired using 301
stitch type.
3.7.2 Stitches per inch. The minimum and maximum number of stitches per inch shall be as
specified in Table III.
3.8 Manufacturing operation requirements. The cap shall be manufactured in accordance with
operation requirements specified in Table III. The contractor is not required to follow the exact
sequence of operations shown.
3.8.1 Marking. The components of the cap shall be marked to insure a uniform shade and size. Any
method of marking may be used except:
