MIL-DTL-29389B(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
N
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
O
1
Seam facing to front lining.
4
Finished appearance. The lining
shall be properly and carefully
aligned and seamed to the facing so
that in the finished vest, the
lining shall be smooth and flat
along the facing without creases,
bulges, overlapping of excess
material, or other defect or
distortion. The eyelet opening
shall not gap or be distorted.
1
Seam facing to front lining.
4
(cont'd)
a. Position right and left front
linings on the respective facing
with the notches at back edge of
facing and front edge of lining
matching.
b. Join front edge of the right
301
SSa-1
10-14
A
A
front lining to the back edge of the
respective facing with a 3/8 inch
seam from the notch at the upper
edge of facing to top notch for the
eyelet opening and from the bottom
notch for the eyelet opening to the
lower edge of facing, leaving an
opening between the notches.
c. Form a 3/16 to 1/4 inch hem in
301
EFb-1
10-14
A
A
the lining, from top to bottom
eyelet opening notches, turning
under the raw edge and catching the
turned under edge in the stitching
1/16 inch from the inner folded edge
of the hem.
d. Tack both ends of the eyelet
301
SSa-1
10-14
A
A
opening.
e. Join lining to left facing from
301
SSa-1
10-14
A
A
the notch at the upper edge to the
lower edge of the facing.
1
Make pleat in front lining.
5
Finish appearance. The pleat shall
finish smooth and flat without
puckers or other distortion, and the
folded edge on the outside of the
lining shall be towards the back.
14
