MIL-DTL-29389B(MC)
Nomenclature: (Item Description)
Name of contractor:
Wool Products Act information
NOTE: Size of characters for "Name of contractor" shall be
minimum 6 point, approximately 1/16 inch.
3.3.9.2. Size label. The size label shall be type VI, class 2 of
DDD-L-20 and shall measure not less than 1-1/2 inches by 1 inch.
The label shall consist of the numerical size designation
specified in 1.2, followed by the letter S, R, L, or XL for
Short, Regular, Long, or Extra Long respectively, as shown by the
following example:
40 R
3.4. Design. The vest shall be in the U.S. Marine Corps design
shown on Figures 1 through 3 (see 6.4), a fully lined, four
button, single breasted vest with four worked eyelets in the
right front for detachable buttons, front and back waist darts,
two-piece back, two hanging pockets with welts shawl type lapel
and adjustable back straps to buckle.
3.5. Patterns. Standard patterns will be furnished to the con
tractor by the Government. The standard patterns shall not be
altered in any way and shall be used only as a guide for cutting
the contractor's working patterns. The contractor's working
patterns shall be identical to the standard patterns. The
standard patterns provide 3/8 inch allowance for joining front
and side front, shoulder, bust dart and back seam and 1/4 inch
allowance for all other seams, with a side outlet according to
the pattern. Standard patterns show size and are marked and
notched for proper cutting, placement and assembly of component
parts.
3.5.1 List of pattern parts. The vests shall be cut from the
specified materials in accordance with the pattern parts as
follows:
ITEM
PATTERN NOMENCLATURE
NO. OF CUT PARTS
Material: Cloth, tropical, wool
1
Front
2
2
Front facing
2
3
Pocket welt
2
6
