MIL-DTL-82189C(MC)
TABLE I. Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
6
Make underarm shields.
(cont'd)
a. Position the two plies of
301
SSa-1
12-16
A
A
material for the underarm shields
with edges even. Seam the two
plies together along the curved
side and bottom edges 3/8 inch from
the edges.
b. Turn the shield right side out,
working out the seamed edges
completely.
c. Press the shields smooth and
flat with a heated pressing iron or
pressing machine.
7
Make shoulder loops.
Finished appearance. The shoulder
loops shall be uniform in
appearance and shall finish smooth
and flat without puckers, pleats,
gathers, or other distortions. The
loops shall finish 3/4 inch +1/8
wide and 1+ 1/8 inch in length.
a. Fold the strip for the loops in
301
EFp-1
12-16
A
A
half lengthwise and seam together
1/4 inch from the raw edge.
b. Press the seam open, smooth and
flat with a heated pressing iron.
c. Turn loops right side out, with
seamline in center of underside and
press smooth and flat with a heated
pressing iron.
8
Stitch and press dart in under
sleeve.
a. Fold the under sleeve, matching
301
SSa-1
12-16
A
A
the cut edges of the sleeve darts.
(cut
Stitch the entire length of the
edges)
dart, 1/4 inch from the cut edges
OSf-1
of the armhole, and taper the line
folded
of stitching to zero at the lower
edge
folded edges.
b. Turn the cut edges of the dart
toward the forearm edge and press
the entire dart smooth and flat
with a heated pressing iron.
16
