MIL-DTL-82172D(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH TYPE
BOB/
NO
OPERATION
TYPE
STCH/IN
NDL
LPR
Make belt loops.
7
(cont'd)
f. Securely bartack the end of the
Bartack
21 per
A
A
buttonhole, catching the ends of the
bartack (silk) (silk)
gimp and thread in the bartack. Trim
the ends of the gimp and thread.
8
Make shoulder straps.
Finished appearance. The shoulder
straps shall be uniform in appearance
and shall finish smooth and flat
without twists, gathers, puckers,
pleats, or other distortions. The
piping shall be evenly worked out and
shall extend uniformly 1/8 inch
beyond the seamed edges of the
shoulder strap. The buttonholes
shall be clean-cut, well made, well
worked over gimp to fit a 27-line
insignia button. The gimp and thread
shall be pulled through to the
underside of the straps.
The
purling of the buttonhole shall be on
the outside.
a. The shoulder straps shall be made
of two plies of basic material piped
with a 5/8 to 3/4 inch wide strip of
piping material specified in 3.3.11.
b. Turn under one edge of the piping
301
EFa-1
12-16
A
A
5/16 inch and stitch through all
plies, 1/16 inch from the turned raw
edge.
c. Position the right side of the
top ply of the shoulder strap on the
hemmed piping with the raw edges of
shoulder strap in line with the
piping stitching line.
d. Stitch shoulder strap to piping
301
SSe-2
10-16
A
A
along the back, front, and collar
(a)
(silk) (silk)
end, 1/8 inch from the inner edge of
the piping.
e. Trim and notch the piping in
accordance with good manufacturing
practice in order to prevent pulling
and to eliminate gathers and bulges
around the collar end.
17
