MIL-DTL-82193C(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
11 Seam sleeve linings.
(cont'd)
a. Position the top sleeve lining
with upper forearm edge in line with
notch at the armhole edge of under
sleeve lining and with notches at the
lower forearm edge of top and under
sleeve lining matching.
b. Stitch the top and under sleeve
301
SSbd-1
10-14
A
A
lining together 3/8 inch from the
to
SSa-1
forearm edge of top sleeve, forming a
tapered outlet on the under sleeve.
c. Join the top and under sleeve
301
SSa-1
10-14
A
A
lining at the backarm with a 3/8 inch
seam.
12 Assemble sleeve and sleeve lining.
Finished appearance. The sleeve
lining seams shall be aligned with
the corresponding seams in the sleeve
and seamed to sleeve without twists,
gathers, puckers, or pleats.
a. The sleeve lining shall extend
301
SSa-1
4-6
A
A
not less than 3/4 inch above top of
or
sleeve. Tack forearm and backarm
Hand
seams of sleeve lining, to forearm
and backarm seams of sleeve
respectively, distributing fullness
in the lining. Tacking to extend
from top of wigan to not more than 5
inches below top of sleeves. When
tacking is done by hand, both ends of
stitching shall be securely
backstitched with not less than three
stitches.
13 Fell turn-up of sleeve lining; press
sleeves.
Finished appearance. The sleeve
linings shall not be short, tight, or
twisted at bottom of sleeves, and
shall extend to within 1 to 1-1/4
inches from finished bottom edge of
sleeve.
a. Pull sleeves through the lining
101
and baste the sleeve lining turn-up
or
to the bottom of sleeves.
Hand
19
