MIL-DTL-82193C(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
5
(cont'd)
Assemble shoulder straps.
c. Trim (basic material) of shoulder
strap evenly 3/8 inch beyond the
outer row edge of the embroidery.
Trim the crinoline evenly along the
embroidered edges so that 1/8 inch of
the background material will be
uniformly exposed between the outer
row of synthetic gold border and
finished edges of strap.
d. Position the rayon lining on the
301
SSa-1
10-14
A/3
A/3
outside of shoulder strap and seam
(cotton) (cotton)
together 1/4 inch from edges at the
front and back, except at collar end
which shall be stitched as close as
possible to the embroidered edge.
e. Cut a vertical opening through
the center of the rayon lining,
allowing room to turn. The opening
shall extend not less than 1 inch
from the collar end. Turn the
shoulder strap through lining
opening, working out the edges of the
seam.
f. Turn under one edge of the cut
Hand
8-10
C
lining and lap to the other half of
(silk)
lining and fell along the folded
edge.
g. Make one eyelet in each strap
Eyelet
20 per
A
A
midway between the back and front
eyelet (silk) (silk)
edges and with the edge of eyelet
(min) (black) (black)
opening 7/8 inch from the rounded end
of straps.
6
Assemble collar.
Finished appearance. The collar
shall be assembled without twists,
gathers, puckers, or pleats. The
eyelets shall be well worked with the
purling on the outside of collar, and
shall finish with a 1/8 inch diameter
opening with the purled edge away
from the opening. The basic material
shall extend uniformly 1/8 inch
beyond the synthetic gold border at
the top and side edges.
15
