MIL-DTL-82168C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
12 Seam sleeve at forearm.
Finished appearance. The forearm
seam shall finish smooth and flat
without twists, gathers, puckers, or
pleats and shall start and finish
evenly.
a. Position the top sleeve with the
301
SSbd-1
12-16
A
A
upper forearm edge in line with the
to
SSa-1
notch in the armhole edge of the
under sleeve. The notches in the
lower forearm edge of the top and
under sleeve shall match. Seam the
top and under sleeve together, 3/8
inch from forearm edge of top sleeve,
forming a tapered outlet on the under
sleeve.
b. Spread open the seam and press
flat with a heated pressing iron.
c. Mark the sleeve end for turn up.
Mark the sleeves for positioning the
braid with the pattern marker.
13 Baste wigan reinforcement to sleeve.
Finished appearance. The wigan shall
be positioned and attached to provide
reinforcement and body to the end of
the sleeve and sleeve ornament
without causing distortions to the
end of the sleeve.
a. Position the sleeve on the wigan
with marks and notches matching as
indicated by the pattern.
b. Tack the left and right sleeves
Hand
to the reinforcement piece along the
or
forearm seam allowance of the top and
101
under sleeve seam allowance
or
respectively.
301
c. Baste the sleeve and
Hand
reinforcement piece together at the
or
mark for the bottom turnup.
101
d. The reinforcement piece shall
extend across the entire width of the
sleeve and under all braid.
18
