MIL-DTL-82163D(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
16 Attach side pockets.
Finished appearance. The edges of
the pocket openings shall finish
smooth and flat without distortion.
Pocket openings shall be of uniform
appearance. The bottom front
corners of the pockets shall be
backstitched, and care shall be
taken to avoid notching the pocket,
on the underside, beyond the width
of the side seam outlet.
a. Position the outside of the
fronts on the facing of the side
pocket in accordance with the
notches for the pocket opening
indicated by marks on the patterns.
b. Seam the front, facing and
301
SSe-2
12-16
A/3
A/3
pocket material together from notch
(a)
to notch, 1/4 inch from the edge of
the front.
c. Cut the depth of the notches
for the pocket opening 1/8 inch
beyond the seam and turn the pocket
to the inside of the front so that
the seam will finish on the inside
of the pocket, 1/8 inch back from
the finished edge of the pocket
opening.
d. Topstitch the front from notch
301
SSe-2
12-16
A/3
A/3
to notch through the pocket
(b)
material and facing, 1/4 inch from
(shows
the finished edge of the pocket
finished
opening.
seam)
e. Position the
301
SSa-1
12-16
A/3
A/3
identification-size instruction
label on the outside of the left
side pocket. Seam label to the
pocket on all four sides, 1/8 inch
from each edge. Label shall finish
approximately 1 inch from the
bottom and front finished edges of
the finished pocket on the side
against the body of the wearer.
18
