MIL-DTL-82163D(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
b. Fold in the raw edges of the
406
EFh-1
10-14
A/3
A/3
strip so that they abut each other
at the center back of the finished
loop. Stitch the folded strip with
a 1/4 inch gage double row of
stitches and with an edge covering
stitch on the back. The margin of
stitching shall be uniformly 1/8
inch from the edges of the finished
loops.
8
Make left fly.
Finished appearance. The left fly
shall finish smooth and flat
without twists, puckers, or
distortions. The stitching shall
be securely caught in the fabric.
a. Position left fly on the left
301
LSbj-2
12-16
A/3
A/3
fly interlining with edges even.
Stitch back edge of the fastener
tape to left fly through
interlining with two rows of
stitches 3/16 to 1/4 inch gage.
The ends of the chain shall be 1/4
to 1/2 inches above the fly notch.
On the finished trousers, the edge
of the chain shall be 1/2 to 5/8
inch from edge at the top end of
fly, tapering to 1/4 to 3/8 inch
from the edge at bottom.
9 Make right fly.
Finished appearance. The right fly
shall finish without bulkiness,
twists, puckers, or pleats.
a. The fly shall consist of one
ply of basic material and one ply
of lining material.
b. Seam lining to front edge of
301
SSe-2
12-16
A/3
A/3
fly with 3/16 inch seam, to within
1 + 1/4 inch from top edge of fly.
c. In the finished trousers, the
upper end of the fly lining shall
extend to the top of the waistband,
over the waistband lining. And the
fly lining extension piece at the
lower end shall extend not less
than 1/2 inch beyond the inseam.
13
