MIL-DTL-29451B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
l. Notch top of polyester twill
103
SSm-1
4-6
A
pocket at front edge of the full
or
width of seam allowance and
306
SSm-1
4-6
A
A
blindstitch inner ply of pocket to
facing.
m. In the finished coat, the width
of the pocket opening shall be 5-1/2
± 1/4 inches for all sizes and shall
not extend into the facing more than
1 inch nor extend into the armhole.
The depth of the pocket shall be not
less than 6 inches.
15 Join the back lining.
a. Tack a 1 inch pleat at center
301
SSa-1
10-12
70
70
back of neck and bottom of lining in
accordance with the notches. The
folded pleat shall be pressed toward
the wearer's left.
16 Join lining side seam.
a. Join the lining fronts and back
301
SSa-1
10-14
70
70
with a 3/8 inch seam.
or
401
b. Overedge stitch the raw edges of
503
EFd-1
10-14
70
70
the side seams together.
or
504
c. Press the side seams toward the
back with a hot steam iron or press.
-or-
d. The lining fronts and back may be
515
SSa-2
10-14
70
70
seamed and overedged together in one
or
operation.
516
or
517
or
518
17 Join lining shoulder seam.
a. Position the front shoulder
301
SSa-1
10-14
70
70
lining to the back shoulder lining
or
with the raw edges even and join with
401
a 3/8 inch seam.
17
