MIL-DTL-28936B(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
4
Make welt. (cont'd)
a. The welt shall be made of a
single ply of basic material, with
fusible, folded in half lengthwise
and reinforced at the inside with
1/4 inch wide cotton tape.
b. Position the tape lengthwise on
301
SSaa-1
10-14
40
40
the welt piece with one edge even
with the fold notch and seam 1/16
inch from the inside edge.
c. Fold the welt lengthwise to the
301
SSe-2
10-14
40
40
outside and close the end of the
(a)
welt with a 1/4 inch seam. Trim
the corners for turning.
d. Turn the welt to the right side
301
SSe-2
10-14
40
40
completely working out the seamed
(b)
edges and corners. Top stitch the
OSf-1
welt uniformly 1/16 inch from the
(fold)
seamed and folded edges. In the
finished vest, the welt shall
finish with the reinforcement tape
stitched to the welt.
5
Make fronts.
a. Position the left and right
front interlining on the underside
of the respective vest front and
fuse.
b. Position facing rayon eyelet
301
SSa-1
10-14
40
40
reinforcement piece on the inside
of right front with front bottom
edges even. Stitch the plies
together 1/8 inch from bottom and
front edges.
c. Position a 1 inch wide by 6
inch long strip of fusible material
on the upper back edge of lining
covering the raw edges and fuse.
Set welt and hanging pocket.
6
Finished appearance. The welt and
hanging pocket shall be set to the
fronts smooth and flat without
twists, gathers, puckers, raw edges
or distortion.
8
