MIL-DTL-28936B(MC)
any manner and shall be used as a guide in cutting the working
patterns. The standard pattern provides for a 1/4 inch allowance
for all seams and are marked and notched for cutting, placement
and assembly of component parts.
3.5.1 List of pattern parts. The vests shall be cut from the
specified materials in accordance with the pattern parts as
follows:
ITEM
PATTERN NOMENCLATURE
NO. OF CUT PARTS
Material:
Basic
1
Front
2
2
Front facing
2
3
Pocket welt
2
Material:
Interlining (fusible)
4
Front
2
5
Facing
2
6
Pocket welt
2
Material:
Rayon lining
7
Eyelet reinforcement
1
8
Eyelet opening, bearer
1
9
Pockets
4
3.6. Construction
3.6.1 Manufacturing requirements. The vests shall be
manufactured in accordance with the operations and the stitch,
seam and stitching type specified in Table I. The contractor is
not required to follow the exact sequence of the operations as
listed in Table I, but all operations specified shall be used in
the manufacturing of the vests.
3.6.1.1. Stitches, seams and stitchings. The stitch, seam and
stitching types specified in Table I shall conform to
FED-STD-751. The number of stitches per inch as specified in
Table I indicate the minimum and maximum number permitted.
3.6.1.2. Tacking and backstitching. Ends of seams and stitching
produced with 301 type stitch, when not caught in other seams or
stitchings, shall be backtacked not less than 1/4 inch; thread
breaks (all stitch types) shall be secured by stitching back of
break not less than 1/2 inch.
6
