MIL-DTL-28936B(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
14
Attach webbing.
a. Attach the 24 inch piece of
301
SSa-1
12-16
40
40
elastic webbing to the left front
slide by looping the elastic
through the open loop, turning the
webbing under the top stitching
with a 1/16 to 1/8 inch stitch.
The other end of the elastic shall
be turned under and topstitched.
15
Attach the third slide.
a. Feed the end of the elastic
through both loops of the third
slide, then through the loop on the
right side and back through the
underside of the third loop (see
Figure 1).
16
Attach velcro to neck straps.
a. Attach the pile piece of velcro
301
SSa-1
12-16
40
40
to the underside of the right neck
strap extension and the hook piece
to the topside of the left neck
strap extension. Velcro to be
centered on their respective neck
extensions, 1/4 inch from the ends
and stitched 1/16 inch around all
edges without causing any bulging
or distortions.
17
Make buttonholes.
Finished appearance. The
buttonholes shall be clean-cut,
well made and correctly positioned.
The stitching shall be securely
caught in the fabric.
a. Mark the location for four
buttonholes on the left front.
Marks will be in accordance with
the buttonhole marker provided.
b. Make a horizontal eyelet-end,
Button-
60 per
40
40
square-bar type buttonhole, cut 5/8
hole
inch at each mark. The inside edge
button-
of the buttonhole eyelet shall
hole
finish 5/8 inch + 1/16 from the
front edge.
13
