MIL-DTL-43335G
TYPE
2.
Replacement of damaged parts.
Care shall be exercised during the
spreading, cutting and
manufacturing operations to
assure that material defects and
damages, are classified in 4.4.3,
are excluded and replaced with
non-defective and properly
matched material.
3.
Join panels (applicable only to
figures 2 and 3).
The two panels shall be seamed at 301
301
10-12
B
B
the center in one direction, with a
lapped, double stitched seam, 1 ±
1/16 inch gauge, with the
stitching 1/8 to 3/16 inch from the
turned edge.
-
or
301 or
LSc-2
8-10
As an alternate, a modified seam
B
B
401
8-10
with butted ends may be used.
LSc-2
B
B
502 or
EFd-1
8-10
Before the seam is formed, the
B
B
503
8-10
ends shall be over-edged.
EFd-1
B
B
The butted ends shall not be more
than 1/8 inch away from each
other.
4
Bind edges:
B
301
BSc-1
10-12
a. Bind all edges of liner with
B
bias cut nylon Oxford. Turn the
raw edges of binding in and stitch
binding 1/16 to 3/16 inch from
edges through all superimposed
plies of binding.
7
