MIL-DTL-43335G
1/ When making the above repairs, the ends of the stitching are not required to be
backstitched.
Type 502, 503 and 401 stitching. Thread tension shall be maintained so that there
will be no loose or excessively tight stitching. All repairs shall be in accordance with 3.5.1.1.l,
a and b.
3.5.1.3 Bartacking. Bartacks shall be 1/2 ± 1/16 inch long and 1/8 ± 1/32 inch wide and shall
contain 28 stitches. Bartacks shall be free from thread breaks or loose stitching.
3.5.2 Manufacturing operations requirements. The poncho liner shall be made in accordance
with all operations listed in table I. The contractor is not required to follow the exact sequence
of operations.
TABLE I
STITCHES
THREAD
SEAM
PER
AND
STITCH
BOBBIN/
INCH
NEEDLE
STITCH
TYPE
LOOPER
No.
MANUFACTURING OPERATION
TYPE
REQUIREMENTS
1.
Cutting:
a. Spread the batting material in
uniform widths with one side of
the lay even. The piles shall not
be stretched or pulled.
b. Cut single panel of the quilted
batting in
Accordance with figure 1, or two
panels in accordance with figure
2 or 3.
c. Cut the nylon oxford for
binding edges on the bias
3 ± 1/8 inches wide. The binding
may be cut, precreased, and
placed on rolls for machine
attachment.
SEAM
STITCHES
THREAD
BOBBIN/
MANUFACTURING OPERATION
STITCH
AND
PER
LOOPER
No.
REQUIREMENTS
TYPE
STITCH
INCH
NEEDLE
6
