MIL-DTL-29389B(MC)
Classification
Examine
Defect
Major
Minor
2. Less than 5/8 or more than
288
3/4 inches wide at narrow end.
3. Straps out of horizontal
alignment by:
289
- more than 3/8 inch but
not more than 5/8 inch.
4. Lower edge of strap less
290
than 3-1/2 inches or more than
3-1/2 inches from bottom finished
edge of back, measured from wide
end of strap.
4.4.3.3. Size measurement. Any measurement deviating from
nominal dimension and tolerance specified in Table II shall be
classified as a size measurement defect. Measurements will be
made at points described in footnotes below Table II.
4.4.4 Bond strength of fusible interlining. The strength of the
bond of the fusible interlining to the outer fabric shall be
tested once every four hours as follows at each fusing press to
determine that adequate fusing is being obtained. Prepare a test
sample by fusing the fusible specified in 3.3.1 under the same
fusing conditions to be used in the manufacture of the vest.
Determine the bond strength of the test sample with a commercial
spring scale (see 6.6). If the bond strength on any test sample
is less than 22 ounces per inch of the width, the fusing
conditions shall be corrected and the bond strength shall be
repeated. Those units represented by this test shall be fused
again and retested. If they fail, they shall be rejected.
5.
PACKAGING
5.1. Packaging. For acquisition purposes, the packaging
requirements shall be as specified in the contract or order (see
6.2). When actual packaging of material is to be performed by
Department of Defense (DoD) personnel, these personnel need to
contact the responsible packaging activity to ascertain requisite
packaging requirements. Packaging requirements are maintained by
the Inventory Control Point's packaging activity within the
Military Department of Defense Agency, or within the Military
Department's Systems Command. Packaging data retrieval is
available from the managing Military Department's or Defense
33
